Freight Cars

Type Specification Type Specification
Design Limit 80 ton Bogie Type Self Steering Bogie
Tare(Average) 21.2 ton Brake Percentage(EMPTY) 72%(AIR)
Production Capacity 67.65m^3 Brake Percentage(LOADED) 19.3%(AIR)
Load (COAL) 58 ton Brake Cylinder 1/10X12
ORIGINALLY DESIGNED FOR COAL Connector / Yoke F/F TYPE
Bearing Size "D" CLASS Brake AIR / Slack Adjuster
SPRING PER BOGIE 10/10 Train Pipe ¢32mm
