Freight Cars

korean

BUSINESS

Type	Specification	Type	Specification
Tare	23 ton	Wheelbase of Bogie	1,753㎜
Loading Capacity	57ton	Height from Bubbler Center to Rail Top	890㎜
Volume	48.7㎡	Gauge	1,435㎜
Maximum Width of Train	2,887㎜	Minimum Curve Radius	91M
Length of Train	13,040㎜	Operating Speed	80~90㎞/h
Length between Bogie Pivots	9,240㎜	Design Speed	120㎞/h
