Freight Cars

korean

BUSINESS

Type	Specification	Type	Specification
Tare	22ton	Wheelbase of Bogie	1,753㎜
Loading Capacity	58ton	Height from Bubbler Center to Rail Top	850㎜
Volume		Gauge	1,000㎜
Maximum Width of Train	2,450㎜	Minimum Curve Radius	91M
Length of Train	12,500㎜	Operating Speed	80~90㎞/h
Length between Bogie Pivots	8,800㎜	Design Speed	120㎞/h
